WEBER Spreader SP 50 BS Smart Force

SPREADER SP 50 BS SMART-FORCE

Compact battery spreader of the latest generation with revolutionary smart features

Numerous innovative and smart additional functions

Huge spreading path for all applications

Tips with interior and exterior spikes

Wrap-around handle for easier handling and reaching around

18V MILWAUKEE M18 HIGH-OUTPUT battery technology (battery not included)

Technical data

Spreading width 805 mm

Spreading force (in the working area) 50 – 501 kN

Max. squeezing force 144 kN

Pulling width 680 mm

Max. pulling force 67 kN

EN class BS50/805-21,8

Weight (ready for use) 21,8 kg

Part no. 1100143

The weight shown here is the operating weight of the device including the 8 Ah MILWAUKEE M18™ High-Output™ battery and the closed underwater cover.

Images are non-binding. We reserve the right to technical modifications.

All SMART-FORCE battery-powered rescue tools have two battery covers (IP-54 and IP-68 cover) included in the delivery.

IP 54 Battery cover for 5.5 Ah & 8.0 Ah

To protect the battery from mechanical damage.

When using the IP 54 battery cover, the tool achieves protection class IP54 (protection against moisture and splash water). Furthermore, a quick battery change is possible in regular operation scenarios.

Part no. 1099352

IP 68 Battery cover for 5.5 Ah & 8.0 Ah

Conversion to underwater use with a few simple steps (suitable for fresh, salt or dirty water).

When using the IP 68 battery cover, the tool achieves protection class IP68. This means that the tool is approved for underwater use up to a depth of 3 m for a duration of 60 minutes (details on underwater use, maintenance, service and care can be found in the operating instructions).

Part no. 1099894

When using 12 Ah 18V MILWAUKEE M18TM HIGH-OUTPUTTM batteries, the larger IP 54 battery cover (part no. 1101405) can also be purchased. This is then suitable for 5.5 Ah & 8.0 Ah & 12.0 Ah batteries.
