Pacific F3D MKII Pacific Structural Fire Helmet

Traditional Style Structural Firefighting Helmet
The Pacific F3D MkII is a cornerstone model of the Pacific range. The F3D MkII is used around the world and has a proven track record of being an extremely safe, robust and long lasting helmet. Continuous improvements to both design and raw materials has meant that the F3D MkII easily exceeds the latest editions of AS/NZS4067:2012 & EN443:2008 while remaining one of the lightest and most comfortable structural firefighting helmets available in the world today.
The F3D MkII features a DuPont™ Kevlar® and fibreglass reinforced composite shell. Within this is a full cranium protective polyurethane inner liner that not only gives excellent impact and penetration protection, but also offers the deceleration impact and side impact protection that is unique to AS/NZS4067:2012 standard. This ensures that the wearer is truly protected from the widest range of hazards faced in the performance of their duties. Available with a 2 point chinstrap as standard or with a “4 point chinstrap in our newly available second generation liner system for even greater comfort. With an adjustable headband size (48cm-68cm with fitting kits), the F3D MkII achieves a secure, comfortable and safe fit for all head shapes and sizes. A wide range of custom neck protectors ensure exacting fit with any collar and hood combination. The liner and headband are designed to comfortably and securely fit over the cradle design of all SCBA masks.
DuPont™ Kevlar® and Fibreglass Reinforced Composite Shell Provides integral strength and excellent penetration protection. This lightweight shell is chemical and UV resistant with inherent heat and flame resistance. Expected service life of 15+ years with proper care and maintenance.
Unique Full Cranium Polyurethane Liner Excellent thermal barrier. Unique crumple zone for superior shock absorption and internal air circulation
Ratchet Adjustable Headband Size 52–65cm (downsizing adjustment kits and XL sizes available). Simple operation with a single gloved hand. Comes with comfortable front and rear sweat padding in leather and is easily removable and replaceable for decontamination.
2-Point Nomex® Chinstrap Single handed adjustment for maximum comfort and stability.
Pacific Quick Release Buckle Can be easily secured, released, and adjusted with a gloved hand.
6-point Ribbon Cradle Harness Fully modular for easy decontamination and replacement without special tools.
Externally Mounted Pozi Stop Face Shield High speed particle protection. Heat and flame resistant. Anti-scratch and Antifog coated. Optically correct. Pozi Stop controls the range of motion for the face shield
Easi On-Off Base Pair for Torch For mounting either a torch (requires torch clip). Optional.
Flame Resistant Neck Protector Choose from Black Nomex®, Blue, Orange or Yellow FR Cotton.
Rear Hanger Allows the helmet to be stored on a hook when not in use.
Reflector Sets Premium 3M™ 680 or 3M™ 8887 Reflective Trims available in a range of colours.
Customised Branding Customised branding, rank markings, or other decals are available by request.
Headband adjusts between 52-65cm. Downsize Kit or Extra Large Headband are also available for smaller or larger head sizes.
Our range of standard colours can be seen here. Custom colours also available, MOQ may apply.
All parts can be removed with simple tools to enable your helmet to be cleaned and maintained. See the User Information Guide for more information.
Helmet certified to the following standards:
- AS/NZS 4067:2012 Structural Firefighting
Face Shield is certified to the following standards:
- AS/NZS 1337.1:2010
- EN 14458:2004
- EN 166:2001
Configuration dependent on certification.
Parts are covered for manufacturing defects and vary from 1-6 years for different helmet components. See the User Information Guide for more information.
